LPD8806 IC Programmable LED Strips

What is LPD8806 addressable LED strip light?

LPD8806 LED supports DC5V low voltage input, a single IC controls 2 LEDs, 2LEDs cuttable, high scanning frequency (>4000HZ), 8806 is a new generation driver chip designed for LED lighting systems, it uses advanced industrial-grade CMOS technology (NMOS The integrated circuit made by the device and the PMOS device) provides multiple constant current drives and grayscale modulation output, which is especially suitable for discrete multi-grayscale full-colour lighting systems.

Unique data clock regeneration mechanism, super signal drive capability, support cascade length over 2000 points; built-in 1.2M oscillator circuit, support FREE-RUN mode, easy to program and design the controller; each channel is built-in independent 256-level PWM The gray-scale control circuit can achieve 1024-level gray-scale effect through programming.

The LPD chip includes a serial shift register and a cascade drive circuit. The gray data is shifted into the serial shift register on the upper edge of the clock, after dumping, it is converted to a multi-port parallel output by pulse width modulation. The serial shift register and the gray and the degree counter can be controlled by different clock signals,while the data and control signals are output to the next level circuit after a strong internal drive.


LPD8806 DC5V Series Flexible LED Strip Lights, Programmable Pixel Full Color Chasing, Indoor Use, 160LEDs 16.4ft Per Reel By Sale
Review stars(0)
Model:DCFLS-5V-LPD8806X160

LPD8806 DC5V Series Flexible LED Strip Lights, Programmable Pixel Full Color Chasing, Indoor Use, 160LEDs 16.4ft Per Reel By Sale

  • Chip Brand: LPD8806
  • Power: 45W//Roll
  • Voltage: DC5V
  • Brightness: 215lm/feet
  • FPCB Width: 10mm
  • FPCB Color:White/Black
  • Waterproof rating: Optional
  • LED Quantity: 32LEDs/m
Various Options In Stock
$49.98 $41.9816% off
Features 1. Universal LPD8806 160 dynamic color chasing, sequencing, changing, and also static color modes available on the Full-Color Controller and dream color Strip.  2. addressable LEDs allow for sequencing modes. Silicone Encased Non-waterproof flexible LED light strip with 160 LEDs high power 5050SMD(Surface Mounted Devices) RGB LEDs programmable for chasing patterns. LPD8806 IC chip...
LPD8806 DC5V Series Flexible LED Strip Lights, Programmable Pixel Full Color Chasing, Indoor Use, 240LEDs 16.4ft Per Reel By Sale
Review stars(0)
Model:DCFLS-5V-LPD8806X240

LPD8806 DC5V Series Flexible LED Strip Lights, Programmable Pixel Full Color Chasing, Indoor Use, 240LEDs 16.4ft Per Reel By Sale

  • IC Type: LPD8806
  • Power: 72W//Roll
  • Voltage: DC5V
  • Brightness: 215lm/feet
  • FPCB Width: 10mm
  • FPCB Color:White/Black
  • Waterproof rating: Optional
  • LED Quantity: 48LEDs/m
Various Options In Stock
$64.98
Features 1. Universal LPD8806  dynamic color chasing, sequencing, changing, and also static color modes available on the Full-Color Controller and dream color Strip.  2. addressable LEDs allow for sequencing modes. Silicone Encased Non-waterproof flexible LED light strip with 240 LEDs high power 5050SMD(Surface Mounted Devices) RGB LEDs programmable for chasing patterns. LPD8806 IC chip...
LPD8806 DC5V Series Flexible LED Strip Lights, Programmable Pixel Full Color Chasing, Indoor Use, 260LEDs 16.4ft Per Reel By Sale
Review stars(0)
Model:DCFLS-5V-LPD8806X260

LPD8806 DC5V Series Flexible LED Strip Lights, Programmable Pixel Full Color Chasing, Indoor Use, 260LEDs 16.4ft Per Reel By Sale

  • IC Type: LPD8806
  • Power: 80W//Roll
  • Voltage: DC5V
  • Brightness: 349lm/feet
  • FPCB Width: 10mm
  • FPCB Color:White/Black
  • Waterproof rating: Optional
  • LED Quantity: 52LEDs/m
Various Options In Stock
$69.98
Features 1. Universal LPD8806 260 dynamic color chasing, sequencing, changing, and also static color modes available on the Full-Color Controller and dream color Strip.  2. addressable LEDs allow for sequencing modes. Silicone Encased Non-waterproof flexible LED light strip with 260 LEDs high power 5050SMD(Surface Mounted Devices) RGB LEDs programmable for chasing patterns. LPD8806 IC chip...
LPD8806 DC5V Series Flexible LED Strip Lights, Programmable Pixel Full Color Chasing, Indoor Use, 300LEDs 16.4ft Per Reel By Sale
Review stars(0)
Model:DCFLS-5V-LPD8806X300

LPD8806 DC5V Series Flexible LED Strip Lights, Programmable Pixel Full Color Chasing, Indoor Use, 300LEDs 16.4ft Per Reel By Sale

  • IC Type: LPD8806
  • Power: 90W//Roll
  • Voltage: DC5V
  • Brightness: 402lm/feet
  • FPCB Width: 10mm
  • FPCB Color:White/Black
  • Waterproof rating: Optional
  • LED Quantity: 60LEDs/m
Various Options In Stock
$79.98
Features 1. Universal LPD8806 300 dynamic color chasing, sequencing, changing, and also static color modes available on the Full-Color Controller and dream color Strip.  2. Addressable LEDs allow for sequencing modes. Silicone Encased Non-waterproof flexible LED light strip with 300 LEDs high power 5050SMD(Surface Mounted Devices) RGB LEDs programmable for chasing patterns. LPD8806 IC chip...
