Super Narrow Flexible LED Strip Lights - 0.12in Width 3mm - DC12V - 0603SMD 37LEDs/Ft - 17Watt 16.4Ft Per Roll LED Tape Lights
  • Super Narrow Flexible LED Strip Lights - 0.12in Width 3mm - DC12V - 0603SMD 37LEDs/Ft - 17Watt 16.4Ft Per Roll LED Tape Lights
  • Super Narrow Flexible LED Strip Lights - 0.12in Width 3mm - DC12V - 0603SMD 37LEDs/Ft - 17Watt 16.4Ft Per Roll LED Tape Lights
  • Super Narrow Flexible LED Strip Lights - 0.12in Width 3mm - DC12V - 0603SMD 37LEDs/Ft - 17Watt 16.4Ft Per Roll LED Tape Lights
  • Super Narrow Flexible LED Strip Lights - 0.12in Width 3mm - DC12V - 0603SMD 37LEDs/Ft - 17Watt 16.4Ft Per Roll LED Tape Lights
  • Super Narrow Flexible LED Strip Lights - 0.12in Width 3mm - DC12V - 0603SMD 37LEDs/Ft - 17Watt 16.4Ft Per Roll LED Tape Lights
  • Super Narrow Flexible LED Strip Lights - 0.12in Width 3mm - DC12V - 0603SMD 37LEDs/Ft - 17Watt 16.4Ft Per Roll LED Tape Lights
  • Super Narrow Flexible LED Strip Lights - 0.12in Width 3mm - DC12V - 0603SMD 37LEDs/Ft - 17Watt 16.4Ft Per Roll LED Tape Lights
  • Super Narrow Flexible LED Strip Lights - 0.12in Width 3mm - DC12V - 0603SMD 37LEDs/Ft - 17Watt 16.4Ft Per Roll LED Tape Lights

Super Narrow Flexible LED Strip Lights - 0.12in Width 3mm - DC12V - 0603SMD 37LEDs/Ft - 17Watt 16.4Ft Per Roll LED Tape Lights

Model: FSLDR-12V-0603X600W3

$39.98

Free Shipping Worldwide On Order Over $199

Please Choose:

PCB Width:





Waterproof Rating:



Qty Discounts Off Price
1-4
$39.98
5-9
$39.18
10-14
$37.98
15+
$36.38
* Discounts may vary based on options above
Qty: -+
ContactUs
  • Product Information
  • Reviews
  • Accessories
  • Product Photos
  • Shop By Project

    Super slim super narrow(PCB width:4mm) single color super bright 3014 SMD(SMD:Surface Mounted Devices) Non-Waterproof Flexible LED Tape strips, Epistar chip, 600LEDs/16.4ft, 16.4ft(5 meters) Per Reel By Sale.

    Our brightest Flexible LED light Strips soft and easy bended for installation. Available in 5 meter (197 in) Waterproof IP65 flexible light strips with adhesive backing and can be stuck just about anywhere. can be cut into 3-LED segments, so you could cut a different length for your project and request. The LED strips Suitable for the average home lighting as well as lighting professionals. 12V DC operation. Dimmable - See compatible LED dimmers

    LED light strips with very soft FPC board as the substrate , high brightness SMD LED as luminous body, LEDs are evenly arranged on the front of the FPC board type . Using the world's leading chip manufacturers, the light source , high brightness, large viewing angle , good quality and stable performance. Easy to maintain. Red, blue, green, warm white, daylight white colors . Is ideal for indoor and outdoor decorative lighting product lines indeed , convenient, energy saving , stable performance . Energy saving , environmental protection. 0603 LED Strip Lights Mainly used in public places, lighting, hotel, home decor home, do backlight used as auxiliary lighting.



    Standards and Certifications




    Product Specification

    LED Strip Type:   SMD 0603  600LEDs/16.4ft

    LED Chip:   Super brights Chip

    Working Temperature:   -4°F (-20°C) ~ 122°F (50°C)

    Storage Temperature:   -40°F (-40°C) ~ 176°F (80°C)

    Light Color:   Warm White, Daylight White,Cool White, RedGreen, BlueAmber (optional)

    Dimension:   16.4ft/roll, every 3 PCS LED can be cut

    LED Quantity:   120 LEDs per 1meter (3.28 ft)

    Lifespan:   50,000+hours

    Warantty:   3 years

    Dimensions:     L500cm(196.8 in ) x W0.3cm(0.11 in ) x H0.10cm(0.04 in )

    Input Voltage(V):   12VDC

    Working Power:   1.5A 17/16.4ft  Max

    Lamp Luminous Flux(lm):   1.1-1.2lm/LEDs   720lm/16.4ft

    Luminous intensity:  250-300mcd

    Color Temperature CCT(White):  Warm White(2800-3200k), Daylight White(4500-6500k), Cool White(7000-8500k)

    Wavelength NM(RGBY):   Red(620-630nm), Green(515-525nm), Blue(465-475nm), Yellow(585-595nm)

    Beam Pattern:   120 degree

    Water Proof:   Non-Waterproof

    CRI (Ra>):  80



    Color Temperature



    Applications

    1. Personal DIY home decoration

    2. The path instructions and exterior decorative outline

    3. Backlit billboards, advertising signs, channel signal signs, etc.

    4. Festive decorations, activities, venue set, exhibition decoration, hall decoration

    5. Chassis decoration, high brake indication, body decoration, interior decoration

    6. Hotels and KTV and other entertainment decoration



    Waterproof Level Description

     IP20 Non-waterproof (The PCB [Printed Circuit Board] surface of the bare , with self-adhesive back, For Indoor);

     IP65 Waterproof (Epoxy cover waterproof, Epoxy Resin,PCB surface is encapsulated with plastic Gel, with self-adhesive 3M back, For Outdoor & Indoor) ;

     IP67 Waterproof (Silicon sleeve waterproof,PCB is encapsulated with silicon tube, with plastic fastener, better waterproof, For Outdoor);

     IP68 Waterproof (Fully waterproof plastic irrigation,PCB both surface and back are encapsulated with plastic Gel, with plastic fastener, top level of waterproof, For Outdoor);



    Installation Instruction




    Notice

    0603 smd will be very very hot when it is working,

    please do not let the LED srip be in touch with anything including the LED Reel!








    Super Narrow Flexible LED Strip Lights - 0.12in Width 3mm - DC12V - 0603SMD 37LEDs/Ft - 17Watt 16.4Ft Per Roll LED Tape Lights

    Super Narrow Flexible LED Strip Lights - 0.12in Width 3mm - DC12V - 0603SMD 37LEDs/Ft - 17Watt 16.4Ft Per Roll LED Tape LightsSuper Narrow Flexible LED Strip Lights - 0.12in Width 3mm - DC12V - 0603SMD 37LEDs/Ft - 17Watt 16.4Ft Per Roll LED Tape LightsSuper Narrow Flexible LED Strip Lights - 0.12in Width 3mm - DC12V - 0603SMD 37LEDs/Ft - 17Watt 16.4Ft Per Roll LED Tape LightsSuper Narrow Flexible LED Strip Lights - 0.12in Width 3mm - DC12V - 0603SMD 37LEDs/Ft - 17Watt 16.4Ft Per Roll LED Tape LightsSuper Narrow Flexible LED Strip Lights - 0.12in Width 3mm - DC12V - 0603SMD 37LEDs/Ft - 17Watt 16.4Ft Per Roll LED Tape LightsSuper Narrow Flexible LED Strip Lights - 0.12in Width 3mm - DC12V - 0603SMD 37LEDs/Ft - 17Watt 16.4Ft Per Roll LED Tape LightsSuper Narrow Flexible LED Strip Lights - 0.12in Width 3mm - DC12V - 0603SMD 37LEDs/Ft - 17Watt 16.4Ft Per Roll LED Tape LightsSuper Narrow Flexible LED Strip Lights - 0.12in Width 3mm - DC12V - 0603SMD 37LEDs/Ft - 17Watt 16.4Ft Per Roll LED Tape Lights
