AC85-240V 750W Infrared Remote Control, High Voltage Controller, Suitable for High Voltage LED Strips, Neon, Rainbow Tubes

Model: CONHV-750W-8
AC85-240V 750W Infrared Remote Control, High Voltage Controller, Suitable for High Voltage LED Strips, Neon, Rainbow Tubes

Select Specifications:

Select Input Voltage:

Select Applied to:

$9.99

Free worldwide shipping on orders over $199

Various options in stock
Qty Discounts Off Price
1-4
$9.99
5-9
$9.79
10-14
$9.49
15+
$9.09
* Discounts may vary based on options above
Qty: -+

DHL, UPS and USPS are delivered to your door, any needs please note at checkout.

Accept the project customization, please contact us for commercial offers and technical support.

  • Product Information
  • Reviews
  • Accessories
  • Images
  • LED Strip Lights Guide

      RF controller adopts advanced computer control chip to control various 110V / 220V lamps with LED as light source, such as: LED high-pressure lamp strips, rainbow tubes and other high-pressure lamps and lanterns; With the advantages of convenient connection and simple

    use;  this product has many kinds of change can realize seven-color jumping, gradual change, stroboscopic, static color and other light changes according to the actual needs of customers, with power saving and memory functions, and avoid frequent setting

    This controller has two kind of input power, AC85V and AC240V, According to the power rule, when the AC is halved, the output power is also halved.

    if you choose AC85V, we will send US plug to you, and AC85V can only output 750watt power, so it can only support Maximum connect 25meter/82feet 85-240V high voltage led strips.

    If you choose AC240V, we will send EU plug to you, and AC240V output 750W, so it can support Maximum connect 50meter/164feet AC85-230V high voltage led strips.

    When calculating the power of your project, please do not exceed 80% of Power Supply capacity when calculating Power Supply size to use in your system.

    So 240V/750W we recommend that you Maximum connect 164feet, 240V/750W we recommend that you Maximum connect 164feet.

    If your lighting project length more than controller output power, please use a 1500W high voltage amplifier. If your outdoor large lighting project needs to achieve effect and color synchronization, we recommend that you use some DMX high-pressure decoders to control them through the DMX console.

    How to connct, please feel free to contact us. sales@superlightingled.com


    Related parameters:

    Input and output voltage: AC85-240V

    Remote control distance: MAX: 10 meters

    Maximum output current: 2A*3

    Maximum stand-alone load: 750W


    Instructions for use:

    1. Insert the light bar plug into the output socket of the controller. The positive pole of the controller and the positive pole of the light bar should correspond. Check whether there is a short circuit in the position of the light bar. If there is a short circuit, please handle it and then turn on the power. Otherwise it will damage the controller and Light.

    2. The power plug is energized, and the remote controller can be used to operate the controller as required.

    3. When installing the controller, install the remote control receiver in an obstacle-free position to avoid remote control failure.


    Feature Mode List

    (1) Power on or off

    (2/9)19 Dynamic mode up and down selection

    (3/8) Speed ​​adjustment

    (4/5) 20 kinds of static colors

    (6/7) brightness adjustment

    (10) 9 dynamic mode cycles


    Standards and Certifications

    AC110-220VCE FCC RoHS ISA SGS ISO led factory


    Connection Diagram

    How to connect the whole roll of led strips

    how to connect ac120v led strip light

    How to use WiFi Amazon Alexa smart switch to connect led strips, you need a wifi switch, click to buy

    how to install wifi led controller to high voltage rgb led tape lights

    How to use Amplifier to connect super long led strips

    how to add amplifier to ac110v led tape light wiring diagram

    How to Use DMX decoder to control large led strip lighting project

    110v ac led strip work with dmx512 led controller



    Applications

    1. Back/task lighting

    2. Cove LED lighting

    3. Retail LED lighting

    4. Display case LED lighting

    5. Accent LED lights

    6. Under cabinet lighting

    7. led stage lighting



    Note

    AC110V or 220V power input, the output high voltage AC110V or 220V article lamp directly. Article AC110v or 220 v meet in the same line, at the same time electricity.

    The quality assurance for one year. Artificial damage or misuse damage is not within the warranty.



    Safety

    Supply input voltage of this product is AC110V or AC220V.

    Shorting output wires my cause damage to controller.

    Always observe proper polarity when connecting high voltage led strip lights and load.

    For indoor use only - this product is not waterproof or weatherproof.

    You can Custom Wire Order, G,V+,R,B



    Package including

    1 x  High Voltage led controller

    1 x  RF remote control

    1 x  4-Pins

    1 x  Piece of User's Manual





    AC85-240V 750W Infrared Remote Control, High Voltage Controller, Suitable for High Voltage LED Strips, Neon, Rainbow Tubes
