Special Price: $20.00 $15.9920% off
Check this flexible led neon lights black led diffuser with 22mm diameter for 10mm led strip lights, this silicone round tube is IP67 waterproof protection for inside IP20 flexible led strip light, 360° light emitting. Made of flexible food-grade silicone material, good bending performance for making led neon signs, good light transmittance, no discoloration, no cracking, and has excellent weather resistance.
Matching single color or color changing led strip lights with 10mm PCB width, the flex silicone led light strip diffuser channel is perfect for outdoor decoration like led outdoor lighting, outdoor advertising, Christmas outdoor decoration, outdoor house lights, etc.
Model: | FLNLT-C22-B |
Tube Material: | Food-grade Silicone |
External Size: | Diameter 22mm |
Inner Width: | 11mm/0.43in |
Max LED Strip Width: | 0.39" (10mm) |
Available LED Strip Type: | Single color led strip, COB led strip, CCT led strip, RGB led strip, RGBW led strip, RGBCCT led strip, Addressable led strip |
Length: | 1m/3.28ft, 2m/6.56ft, 5m/16.4ft |
Diffuser Surface: | Black |
Accessories: | End Caps (come with), Mounting clips (Please choose in the "Kit" option) |
Waterproof Rating: | IP67 |
UV Resistant: | Yes |
Beam Angle: | 360° |
Working Temperature: |
-50°C to 200°C |
LED Neon Light Knowledge Source: |
Note:
The product does not include led light strips.
If you buy our LED strips at the same time, we can make LED neon lights for you for free. You only need to make a note when ordering.
If you insist on completing the production of neon lights by yourself, you can read: How To Put A Flexible LED Strip Light Into A Silicoen Tube?
We are not responsible for any damage caused by your own operation!
Flex LED Neon Tube Installation:
There are three installation methods for neon silicone tubes, one is to install with mounting clips (this link include 10 pcs, if you need extra led mounting brackets, please purchase them by yourself), easy operation. 1m silicone tube for led strip lights has two mounting clips, 2m has four, and 5m has ten.
The second is to put the flex led neon tube into the aluminum channel, this installation method is suitable for linear lighting projects.
And the third is to use flexible profiles for curved path lighting, which has great bending freedom.
Applications:
Flexible LED neon tube with COB/Single color/CCT/RGB/RGBW/RGBCCT/Addressable LED strip has wide applicability. It can be applied to the following scenes.
1.Building outline lighting
2.Hotel lighting project
3.Bridge lighting project
4.Cultural tourism town lighting project
5.City park lighting project
6.Festival atmosphere decoration project
7.Airport lighting project, etc.
These images were taken with Canon EOS 5D Mark IV and the studio light source is provided by Ra 98's full spectrum LED strip to realistically reproduce the colors of the item itself. All copyrights are created by the superlightingled team, please feel free to browse and download if you are a registered user!
![Black LED Neon Light Diffuser Round Silicone Tube 360° Emitting Φ22 Black LED Neon Light Diffuser Round Silicone Tube 360° Emitting Φ22](images/LED Lights Images/FLNLT-C22-B.jpg)
![Black LED Neon Light Diffuser Round Silicone Tube 360° Emitting Φ22 Black LED Neon Light Diffuser Round Silicone Tube 360° Emitting Φ22](images/LED Lights Images/FLNLT-C22-B_1.jpg)
![Black LED Neon Light Diffuser Round Silicone Tube 360° Emitting Φ22 Black LED Neon Light Diffuser Round Silicone Tube 360° Emitting Φ22](images/LED Lights Images/FLNLT-C22-B_2.jpg)
