Breakpoint-continue WS2813 DC5V 480 LEDs Individually Addressable Dream Color RGB LED Strip Lights Programmable Flexible LED Light

Model: DCFLS-5V-WS2813X480
Breakpoint-continue WS2813 DC5V 480 LEDs Individually Addressable Dream Color RGB LED Strip Lights Programmable Flexible LED Light
  • Breakpoint-continue WS2813 DC5V 480 LEDs Individually Addressable Dream Color RGB LED Strip Lights Programmable Flexible LED Light
  • Breakpoint-continue WS2813 DC5V 480 LEDs Individually Addressable Dream Color RGB LED Strip Lights Programmable Flexible LED Light
  • Breakpoint-continue WS2813 DC5V 480 LEDs Individually Addressable Dream Color RGB LED Strip Lights Programmable Flexible LED Light
  • Breakpoint-continue WS2813 DC5V 480 LEDs Individually Addressable Dream Color RGB LED Strip Lights Programmable Flexible LED Light
  • Breakpoint-continue WS2813 DC5V 480 LEDs Individually Addressable Dream Color RGB LED Strip Lights Programmable Flexible LED Light
  • Breakpoint-continue WS2813 DC5V 480 LEDs Individually Addressable Dream Color RGB LED Strip Lights Programmable Flexible LED Light
  • Breakpoint-continue WS2813 DC5V 480 LEDs Individually Addressable Dream Color RGB LED Strip Lights Programmable Flexible LED Light
  • Breakpoint-continue WS2813 DC5V 480 LEDs Individually Addressable Dream Color RGB LED Strip Lights Programmable Flexible LED Light

Select Specifications:

Starting at: $74.98

Free worldwide shipping on orders over $199

Various options in stock
Qty Discounts Off Price
1-4
$74.98
5-9
$73.48
10-14
$71.23
15+
$68.23
* Discounts may vary based on options above
Qty: -+

DHL, UPS and USPS are delivered to your door, any needs please note at checkout.

Accept the project customization, please contact us for commercial offers and technical support.

Related Products

  • Product Information
  • Reviews
  • Accessories
  • Images
  • LED Strip Lights Guide

    WS2813 led strip has 4 wires for sending data - one V+ pin, one GND pin, and two data pins. Dual-signal wires version, signal breakpoint continuous transmission. If one LED is damaged, it will not affect the other LEDs working, unless two continuous LEDs are damaged.

    WS2813 is individually addressable. Every 1 WS2813 IC control 1 LED, every LED can be shown any color you want. By varying the level of red, green, and blue (RGB) per LED, many color combinations can be made.

    This WS2813 96LEDs/m RGB led strip comes with a 4-pin JST SM connector on each end. Every LED segment can be cut. You can also connect multiple WS2813 strips together to make them longer. To power this WS2813 strip, you need a 5V power supply.

    5V WS2813 LED has wide compatibility. Works great with Arduino, Adafruit NeoPixel Library, Fast LED library, and Raspberry Pi, etc.



    WS2813 Technical Features

    The control circuit and RGB chip are integrated into 5050 components, to form an external control pixel

    Refresh Frequency updates to 2 KHz. It supports the lower frequency and inexpensive MCU.



    WS2813 Datasheet PDF



    Product Specification

    Item:  96LEDs/m WS2813 RGB LED Strip
    LED Type: SMD5050
    Light Color: Addressable RGB
    IC Type: WS2813 IC
    Working Temperature:  -4°F (-20°C) ~ 122°F (50°C)
    Storage Temperature: -40°F (-40°C) ~ 176°F (80°C)
    Dimension: L5000mm*W12mm*H0.25mm
    Waterproof Rating:  Non-waterproof IP20, Indoor Waterrpoof IP65, Outdoor waterproof IP67 IP68
    LED Quantity: 96 LEDs/m, 480 LEDs/roll
    IC Quantity: 480 ICs/roll, 1 IC drives 1 LED
    Input Voltage(V): 5VDC
    Power: 18W/m, 90W/roll
    Beam Pattern: 120 degree
    Lumen: 20-22lm/LED
    Lifespan: 30,000+hours



    Pin Function

    DO: Control data signal output

    DI: Control data signal input

    BO: Backup control data signal output

    BI: a Backup control data signal input

    GND: Data &Power Grounding
