Complete ES32 Channel Tread Intelligent Motion Sensor LED Stair Lights Kit DC12V COB LED Lighting Set
Related Products
Complete ES32 Channel...
$190.00 $159.9816% off
ES32 PIR Motion Sensor...
$299.98 $259.9813% off
DC12/24V COB 10m Long LED...
$12.98 $11.988% off
PIR Sensor LED Stair...
$79.98 $54.9831% off
28 Steps PIR Sensor Stair...
$63.98
CT3252 Motion Activated...
$119.98
Motion Sensor Stair...
$279.98-
Special Price: $190.00 $159.9816% off
This motion sensor led stair lights kit contain a smart ES32 controllers can be selected, each with two motion sensors, and the sensors are fixed by screw thread. (A new APP controlled intelligent AC switch option has been added to allow the whole stair light system to be time controlled to achieve the purpose of not working during the day and working at night.)
Install the two motion sensors at both ends of the first and last stages of the stair lighting, install COB led strips in the middle, and connect these light strips to the output ports of the controller. The power supply supplies power to the controller and the COB led strips. In this way, when people walk near the motion sensors, they will have the effect of flowing water up or down or stepping on the light strip along the stairway lighting. The LED lights come on when people come, and the LED lights go off when people go. The speed of stepping or running water is adjustable. Note that after determining the regulating speed, it is fixed. We can only step or run water at a fixed speed. Note: The ES32 controller is not available in all-lights-on mode.
COB led strips installed on the steps: stepping effect. Led strips on both sides of the Staircase Lighting: flowing water effect. What is COB led strip lights?
2. The motion sersor led stair lights kit uses the DC12V COB led strip(PCB width 8mm). The step lights strip and the controller both come with fast connectors, which is the default. The option "Step Light Extension Cable" is to connect the step lights to the ES32 controller, please be sure to choose. The length of the step light extension cable is determined by how far your light strip is from the controller.
The length of the COB led strip is 0.6m/1.96ft by default, 0.5m/1.64ft, 0.8m/2.62ft, 0.9m/3ft, 1m/3.28ft, 1.2m/4ft are available, please contact us if you need to customize the length.
3. There are many options for the color of the COB led strip, all single color or multi-color cycle(Red-Green-Blue-Yellow-White-Red, it means that the first step is a red light strip, the second step is a green light strip, the third step is a blue light strip, the fourth step is a yellow light strip and the fifth step is a white light strip. And so on.). We also provide the option of white COB LED strips plus two 5m addressable white led strips, which can have both a stepping effect and a flowing water effect.
| Single color | Red / Green / Blue / Yellow / Warm White / Daylight White / Natural White / Pink / Ice Blue / Purple |
| Multi-color cycle (color fixed, not adjustable, can't change the color) | Red (first step) - Green (second step) - Blue (third step) - Yellow (fourth step) - White (fifth step) - Red (sixth step) ... |
| White COB LED strips + two 5m addressable white led strips |
3000K + 2*5m 3000K Color Chase LED Strips 6000K + 2*5m 6000K Color Chase LED Strips |
4. The power supply is a wide-voltage power supply that supports AC110V and AC220V input. The power supply is not waterproof and is equipped with an AC plug. The power supply wattage is different for different steps.
Power = Strip Length (meter) * Strip power per meter * 1.2
| Steps (0.6m/1.96ft) | Total Power |
| 8, 10 | 75W |
| 12, 14 | 100W |
| 16, 18, 20 | 150W |
| 22, 24, 26, 28 | 200W |
5. The COB led strip can be installed with LED aluminum profiles, which can dissipate heat and emit light more evenly and softly, and comes with more beautiful installation effect.
The aluminum profile has two colors, black and white, and the led light diffuser is a PC milk white shell. There are three aluminum channel types you can choose: 90° Light-emitting Corner Mount LED Channel, Recessed Aluminum LED Strip Diffuser With Flange, Surface Mount LED Aluminum Profile.
6. For the waterproof option, we recommend you choose the aluminum profile option, the COB strip will be sealed with an IP67 silicone sleeve, and then paste in the aluminum profile with backing adhesive, connected to the controller output interface with a transparent waterproof cable on one side, and the controller will be installed in a plastic waterproof box, the entire system will use a waterproof power supply, ensuring that all models and contact points are IP67 waterproof and can be used outdoors, providing lighting solutions for your decks and outdoor steps.
Standards and Certifications
Specification
| LED Strip Type | COB LED Strip |
| Controller Type | ES32(32-way) |
| Motion Sensor Fixed | Screw thread |
| CRI(RA>) | 90 |
| Light Color | Daylight white(6000K-6500K) / Neutral white(4000K-4500K) / Warm white(2700K-3200K) / Red*Green*Blue*Yellow*White / Green / Red / Blue / Yellow / Pink / Ice Blue / Purple |
| Input Voltage | DC 12V/24V |
| Working Temperature | -4°F (-20°C) ~ 122°F (50°C) |
| Storage Temperature | -40°F (-40°C) ~ 176°F (80°C) |
| LED Strip Length | 0.5m / 0.6m / 1m |
| PCB Width | 8mm |
| LED Quantity | 312 LEDs per meter/3.28ft |
| Light Strip Extension cord | 0.2m / 1m / 2m |
| Cut Length | 0.98"(25mm) |
| Beam Pattern | 180 degree |
| Power | 8-10W/m |
| Power Supply Waterproof | Non-waterproof(IP20) |
| Power Supply Input | Wide-voltage |
| Aluminum Profile Color | No / White / Black |
| Light Emitting Direction of Aluminum Profile | No / Forward / Forward+Flange / 90 degree |
Product List:
1*Srair Light Controller with Two Motion Sensors ( ES32 would come with one Daylight Sensor)
N*COB LED Strip
1*DC Power Supply with An AC Plug
N*Light Strip Extension Cord ( used to connect the Srair Light Controller and COB LED Strip)
N*LED Aluminum Profile(Optional)
How to use and install Motion Sensor led stair light kit?
ES32 LED Stair Controller Lighting Modes:
1) Color flow LED stair lighting;
2) Step-by-step staircase lighting;
3) Stair light step-by-step and color flow.
What is the electrical box used for?
The electrical enclosure box is used to store the stair controller and DC power supply to make your whole staircase installation look more simple and clean.
| By : Hunter Cordell Date Added: 12/14/2021 | |
| I've always wanted these and they always felt like, absurdly out of reach. In my limited research these felt like the only thing even close to what I was looking for. Took my handyman almost a full day to install these, and probably another few hours to reinstall the drywall and sheet rock that he tore through to install my lights, but man oh man its gorgeous. | |
Rating:
|
|
| By : Mark Hahn Date Added: 12/08/2021 | |
| These were used on a new staircase build, The LEDs are controllable for timing and brightness and are very easy to install. The power source is hooked up from an extension cord wire then it goes to the controller. The LEDs cascade perfectly going up or down. The wires supplied are plenty long to go up 15-stairs or more. Very happy with this purchase and the company stands behind it they are very good to work with. Highly recommended. | |
| Rating:
|
|
| By : Kyle Kirbatski Date Added: 11/27/2021 | |
| Great lights. Working good so far. Everything you need to install is included. They are a hit with everyone who see them, including me. | |
| Rating:
|
|
