Special Price: $60.00 $29.9850% off
COB RGBW LED strip light is a new type of LED strip light on the market. Integrating the unique design of the onboard chip which combines the RGBW COB chip and the fluorescent film LED chip, is directly packaged on the PCB. Frees up space and expands the light-emitting angle, increasing the measure LED strip width to 12mm/0.47in, greatly solving the heat dissipation problem.
RGBW COB LED strip light, compared with the COB RGB LED light strip, with extra purer white color, the color temperature is 3000/4000/6000K option, work with the color-changing RGBW LED controller, you can control the single color(R/G/B/W) changing by the Bluetooth/Wifi smartphone APP control, can be also controlled by the third party, like Amazon Alexa, google assistant, with the timer/music/group function.
The input voltage of this RGBW LED strip light is DC24V, every 50mm/1.97in cuttable, total 784chips per meter, softly achieve the whole roll without light spot, perfectly match with the LED aluminum channel or LED neon tube, which is an ideal choice for display, exhibition, under-cabinet, concave lighting applications, etc.
We can help you customize the length and waterproof rating, by inserting the RGBW COB LED strip into the silicone, and do waterproof at two sides, the wide will only increase 1-2mm, suitable for indoor & outdoor use.
This product has been upgraded to a version with no resistors on the surface. Please note the updated images for customers who have made a purchase.
Product Features
|
• 180degrees emitting angle • Super density 784Chips/m • Whole roll without light spot • 3000/4000/6000K white color optional • Every 50mm/1.97in can be cut • IP67 waterproof available • High CRI 90+ |
LED Strip PDF Download
RGBW COB LED Strip Spectrum Test Report
(3000K), (4000K), (6000K)
Standards and Certifications
Product Specification
| LED Strip Type |
COB LED (COB Flexible led strip light specification ) |
| LED Chip | Epistar Chip |
| Input Voltage | DC24V |
| Current | 3A/roll |
| Working Temperature | -20℃~+45℃ |
| Storage Temperature | -20℃~+60℃ |
| Power | 14.4W/M, 72watt/roll |
| PCB Width | 12mm/0.47in |
| LED Quantity | 784Chips/m(R/196,G/196,B/196,W/196) |
| White Color | Warm White(2800-3200K); Netural White(4000-4500K); Daylight White(6000-6500K) |
| Cut Length | 71.4mm/2.81in |
| PCB color | White |
| Color Rendering Index | Ra＞90 |
| Beam Angle | 180° |
| Length | 5m/16.4ft |
| CRI | 90+ |
| Waterproof Rating |
|
| Lumen |
3000k: Red-300 lm/W Green-1739 lm/W Blue-272 lm/W W-1046 lm/W RGBW-714 lm/W 4000k: Red-305 lm/W Green-1678 lm/W Blue-258 lm/W W-1081 lm/W RGBW-800 lm/W 6000k: Red-336 lm/W Green-1732 lm/W Blue-259 lm/W W-1056 lm/W RGBW-726 lm/W |
How to choose LED strip lights kit?
You can choose the controller or power supply or controller plus power option for this COB LED strip. Of course, only the COB LED light is also completely possible. The difference is whether you need to control the LED brightness change of the COB strip and whether you can supply power to the light strip.
In the following table, we list for you which products you will get if you choose the kit. If you have other needs, please check our product categories.
|
LED Strip |
Kit | Knowledge |
| 5m/16.4Ft COB LED Strip |
Controller: WB5, you can also visit out RGBW Controller Series Power supply: 24V 100W MW power supply + AC Plug |
How to choose led strip light controllers? |
What is the difference between new COB RGBW led strip and RGBW LED strip?
COB RGBW LED strip adopts the chip-on-board tech, with a smaller LED chip, and more density than the normal RGBW LED strip. The distance between both LED chips is so short that the whole roll is without a light spot.
Emitting angle of the RGBW COB LED strip is 180degrees, with the uniform lighting, the whole roll with more brightness than the ordinary RGBW LED strip.
Wiring Diagram: How to Wire RGBW LED Strips?
