RF CCT Control System
Skydance wireless CCT series includes 2/3/4/5 channels controller, remote control, panel controllers&remote and dimmable LED driver. Through product different collocation to achieve light on/off control, color temperature adjustment, brightness adjustment, group partition, scene, timing, sensor and other intelligent control functions.
1. The CCT (2 channel) controller can be matched with all remote controls (including hand-held remote, panel remote, desktop remote of dimming, CCT and RGB+CCT).
2. Adopt 2.4G wireless technology, the remote control distance is 30 meters, the controller has the cascade function, through the signal forwarding between the controllers can reach hundreds of meters of control distance.
3. The 3/4/5 channel controller can be used as a CCT controller when connect with dual color CCT light and matching the CCT remote control.
4. One controller can be matched with up to 10 remote controls. A controller can match in the same remote control of different zones, to achieve flexible grouping function.
5. A remote control can control single or multiple zones, each zone can be matched with an infinite number of controllers.
6. All controllers on the same zone are automatically synchronized.
7. The CCT series includes constant voltage controller, constant current controller, CCT remote control, CCT panel, constant voltage dimmable LED driver, constant-current dimmable LED driver, WiFi-RF converter and power repeater, etc.
Shop By RF CCT Control System Type
RF CCT CV Controller1. DC12/24/36/48V power input, 2/4 channels PWM constant voltage output to get 1/2 group dual color CCT.
2. PWM achieve 4096 levels flicker-less dimming.
3. Wireless 2.4G, remote control distance is 30 meters, with cascade function, achieve hundreds of meters of control distance.
4. Can accept 1-10 remote control, achieve partition control through remote control.
5. When match with CCT remote control, 3/4/5 channels controllers also can be used to control dual color light.
6. With remote control, panel, WiFi-RF converter, etc., constitute the lighting control system.
7. Various dimming methods: push switch, touch button, knob, digital tube display.
8. Over-heat / Over-load / Short circuit / Reverse polarity protection.
9. Work with power repeater to expand output unlimitedly.
RF CCT CC Controller1. Set as dual color CCT controller by DIP switch.
2. DC12/24/36/48V power input, 4 channels PWM constant current output to get 1/2 group dual color CCT.
3. 350/700mA output, other currents (150-1200mA) need to be customized.
4. PWM achieve 4096 levels flicker-less dimming.
5. Wireless 2.4G, remote control distance is 30 meters, with cascade function, achieve hundreds of meters of control distance.
6. Can accept 1-10 remote control, achieve partition control through remote control.
7. With remote control, panel, WiFi-RF converter, etc., constitute the lighting control system.
8. Connect with external push switch to achieve on/off and 0-100% dimming function.
9. Short circuit / Reverse polarity protection.
RF CCT Remote ControlThe hand-held CCT remote control can be divided into single zone and 4zone, and 7#AAA battery or button battery powered, providing customers with a variety of choices.
1. Used for dual color LED lights to realize on/off, color temperature &brightness adjustment, group partition and scene functions.
2. Wireless 2.4G, remote control distance is 30 meters, control distances of several hundred meters are achieved by cascades between controllers.
3. The remote has a standby time of six months to two years, depending on how often it is used.
4. Each remote can theoretically be matched with an infinite number of controllers. Each zone of a multi-zone remote can also be matched with an unlimited number of controllers.
5. Each controller can be matched with 1-10 remote controls. A controller can be matched in different zones of a remote control.
RF CCT Panel Remote ControlThe CCT panel remote control can be divided into single zone and 4zone, including button panel, knob panel and touch glass panel (white & black glass), and high voltage AC100-240V, low voltage DC12-24V, 7#AAA battery or button battery powered, providing customers with a variety of choices.
1. Used for dual color LED lights to realize on/off, color temperature &brightness adjustment, group partition and scene functions.
2. Wireless 2.4G, remote control distance is 30 meters, control distances of several hundred meters are achieved by cascades between controllers.
3. The battery-powered panel remote has a standby time of six months to two years, depending on how often it is used.
4. Each remote can theoretically be matched with an infinite number of controllers. Each zone of a multi-zone remote can also be matched with an unlimited number of controllers.
5. Each controller can be matched with 1-10 remote controls. A controller can be matched in different zones of a remote control.
6. All CCT panel controllers (including constant voltage controller, DMX512 master)can be used as a remote control other RF controller, can also be used as a RF controller to accept other remote control.
RF CCT CC Dimmable LED Driver1. AC100-240V input, DC3-21V output, 2 channel PWM constant current output to get dual color CCT.
2. Max output power 12W.
3. 600mA output, other currents (<600mA) need to be customized.
4. Dimming interface: RF Wireless, AC Push-Dim.
5. The same control function as Skydance RF dimming constant current controller.
6. Over-heat / Over-load / Short circuit protection, recover automatically.
7. 5 Year, 50,000hr warranty.
RF CCT CV Dimmable LED Driver1. AC100-240V input, DC12/24V output, 2/4 channel PWM constant voltage output to get 1/2 group dual color CCT.
2. Output power 40-150W.
3. Dimming interface: RF Wireless, AC Push-Dim.
4. The same control function as Skydance RF CCT constant voltage controller.
5. Over-heat / Over-load / Short circuit protection, recover automatically.
6. 5 Year, 50,000hr warranty.
