How to connect the color chasing LED strip light kit?
1. Determine the power of the LED strip.
Over-driving the controller or wrong wiring will cause the lights to flicker and even damage the light strips. When connecting a single roll of ultra-long lighting, to avoid voltage drop, you need to power at two ends of LED strip light; when connecting multiple rolls of LED strips, you need to use an LED power amplifier; for a single roll of short-distance lighting, you can directly connect an LED strip, controller to LED power supply or choose our LED strip light kit.
2. Master the correct wiring method.
Single Signal LED Strips: VCC, DAT, GND; Dual Signal LED Strips: VCC, DAT, CLK, GND; Breakpoint Resume Series: VCC, DAT, B1, GND(B1 can be connected to the DAT/CLK/GND interface).
