RF & Tuya WiFi LED Controllers
.jpg "100 to 240VAC WiFi and RF Smart Dimmer Light Switch SS-C(WT)")
(0)Model:SS-C(WT)
100 to 240VAC WiFi and RF Smart Dimmer Light Switch SS-C(WT)
- Input voltage: AC100-240V
- Input current: 0.02A
- Relay contacts: single-pole, single-throw (SPST) relay
- Input signal: WiFi + RF 2.4GHz + AC Push switch
- RF control distance: 30m(Barrier-free space)
- Warranty: 5 years
- Size: L60 x W60 x H40mm
- Gross weight: 0.074kg
Possessing 10A dry contact main rated output capability and zero cross switching technology, SS-C(WT) is a WiFi and RF relay smart life light switch ensures smooth switching action. This switch support users to achieve remote control through Tuya app, including the lights on and off, delay setting and timed activities. To accomplish voice control ease, our led relay switch also supports a range...
.jpg "3 Button 5 to 24VDC Tuya WiFi RGB CCT LED Controller VD5(WT)")
(0)Model:VD5(WT)
3 Button 5 to 24VDC Tuya WiFi RGB CCT LED Controller VD5(WT)
- Input Voltage: 5-24VDC
- Output voltage: 5-24VDC
- Output current: 5CH, 1A/CH
- Input signal: WiFi + RF 2.4GHz + 3 button
- Dimming level: 256 levels
- Size: W120 x L43 x H27mm
- Gross weight: 0.057kg
- Material: Gas-phase Silica Gel
VD5(WT) is a WiFi and RF 5 channel RGB CCT LED controller with 3 buttons that make it simple to operate the light modes, brightness, color temperature. Also, through the Tuya app, this LED lights controller has remote control capabilities for users to control the RGB color, color temperature, and brightness adjustments in addition to features like scene editing, timer operations, delayed on/off,...
(0)Model:F3-D(WT)
3 Buttons IR Tuya RGB LED Controller F3-D(WT)
- Input Voltage: DC5-24V
- Output Current: 3CH, 1.5A/CH
- Output Power: 22.5W/54W/108W
- Control Mode: Tuya APP+IR+3 button
- Dimming Curve: Logarithmic
- PWM Frequency: 2KHz
- Size: W130 x L60 x H26mm
- Warranty: 5 years
It appears you're describing a WiFi and infrared remote-controlled RGB LED controller with specific features and capabilities. Here's a breakdown of the key features and functionalities: Channels and Voltage: This LED RGB controller has three channels, which means it can control RGB LED strips with separate control of red, green, and blue channels. It operates at a constant voltage. Tuya...
.jpg "6 Buttons Tuya Wifi LED RGBW Controller with RF control M5(WT)")
(0)Model:M5(WT)
6 Buttons Tuya Wifi LED RGBW Controller with RF control M5(WT)
- Input Voltage: DC12V-24V
- Output current:5CH,3A/CH
- PWM Frequency: 2000Hz (default)
- Dimming Curve: Logarithmic
- Output Power:5×(36-72)W
- Size: L162 x W42 x H26mm
- Output voltage: 5×(12-24)VDC
- Input signal: WiFi + RF 2.4GHz
M5(WT) is a 6 buttons LED controller which perfects for RGB, RGBW or RGB CCT LED lights. Integrating with the tuya smart life app cloud-based access control, this compact controller supports users to control light switch, adjust brightness, color temperature and RGB color changes. It can be set with five different lighting types to provide you with a different visual experience. Compatible with...
(0)Model:CM-SS(WT)
CM-SS(WT) Smart Automatic Curtain Opener And Closer, WiFi Tuya Alexa + RF Control
- Input Voltage: 100-240VAC
- Output Current: Max. 2A (AC)
- Output Power: 200-480W
- Size: W56 x L50 x H28mm
CM-SS(WT) module is a smart curtaion controller that enables users to remotely control the opening and closing status of curtains, providing a more convenient use experience and intelligent home life. With this smart curtain module, your curtains can automaticly opened and closed with WiFi Tuya SmartLife APPs and Alexa voice commands control methods, it's also available to match a RF remote...
(0)Model:VD3(WT)
Mini 3 Button Tuya RF RGB LED Controller VD3(WT)
- Input Voltage: 5-24VDC
- Output Current: 3CH, 1.5A/CH
- Output Power: 22.5W/54W/108W
- Control Mode: Tuya APP+RF 2.4GHz+3 button
- PWM Frequency: 2KHz
- Size: W120 x L43 x H27mm
1. RGB LED Controller: The controller is designed to control RGB LED lighting, allowing you to adjust the color, brightness, and modes of the lights. 2. WiFi & RF Connectivity: It supports both WiFi (Tuya APP cloud control) and RF (Radio Frequency) communication. This means you can control the LEDs remotely using a mobile app and also through RF signals. 3. Tuya APP Integration: The Tuya app...
.jpg "3 Buttons IR Tuya WiFi RGBW LED Controller F4-D(WT)")
(0)Model:F4-D(WT)
3 Buttons IR Tuya WiFi RGBW LED Controller F4-D(WT)
- Input Voltage: DC5-24V
- Output Current: 4CH, 1.5A/CH
- Output Power: 30W/72W/144W
- Control Mode: Tuya APP+IR+3 button
- Dimming Curve: Logarithmic
- Dimming Curve: Logarithmic
- Size: W130 x L60 x H26mm
- Warranty: 5 years
The device you're describing is a WiFi and IR-controlled 4-channel constant voltage RGBW LED controller, designed for controlling RGBW LED strips. Here's a breakdown of its features: Tuya APP Cloud Control: This wifi RGBW led controller is compatible with the Tuya Smart App, allowing you to control various functions remotely through the cloud. Voice Control: The wireless lighting...
(0)Model:WT-SPI
5-24VDC WiFi Tuya App & RF Remote 2CH/4CH RGB/RGBW SPI LED Controller WT-SPI
- Input voltage: 5-24VDC
- Input signal: Tuya APP + RF
- Output Signal: SPI(TTL)
- Pixel Dots: MAX.1000
- Output Channel: (DAT+CLK)x2
- Output Channel: DATx4
This is a Smart SPI Controller to control DC5V/DC12V/DC24V Addressable LED Strip Lights, available with Tuya smartphone APP control and R9 RF remote control. It is compatible with single-signal or dual-signal addressable RGB and RGBW IC chips. Output 2 channels dream color lighting, max control 1000 pixels. If you use it to control a 3-pin single-wire digital LED strip, the...
(0)Model:SS-L(WT)
SS-L(WT) High Voltage Tuya Wifi and RF Smart Light Switch Alexa
- Input Voltage: 100-240VAC
- Output power: 1500-3600W
- RF control distance: 30m
- Input signal: Tuya+Push+RF
- Operation temperature: Ta: -30℃ ~ +55℃
- Output Current: 15A (Resistive load); 10A (inductive load)
Introducing our cutting-edge SS-L(WT) smart home light switch, a versatile solution designed to seamlessly integrate into your modern living space. This smart light switch, equipped with WiFi and RF capabilities, offers a streamlined and intelligent way to control your single-color LED lamps, traditional incandescent, and halogen lights. With the Tuya APP's cloud control feature, you can...
.jpg "100-240VAC 3CH*1A Wi-Fi & RF High Voltage Tuya Smart LED Controller S3(WT)")
(0)Model:S3(WT)
100-240VAC 3CH*1A Wi-Fi & RF High Voltage Tuya Smart LED Controller S3(WT)
- Input signal: Tuya+RF+Push-DIM
- Input voltage: 100-240VAC
- Input current: 3.2A
- Output current: 3CH,1A/CH
- PWM frequency: 2000Hz
- Warranty: 5 years
WiFi & RF 3-Channel High Voltage LED Strip Controller. ● 3 channel high voltage LED strip controller, can control a maximum of about 50 meters of high voltage LED strip, different LED strips may have differences. ● 3 in 1 function, used for control RGB, color temperature, or single color LED strip. ● Tuya APP cloud control, support on/off, RGB color, color temperature, and...
.jpg "9-45VDC 1CH*(100-450mA) 12W Zigbee Constant Current Dimable LED Driver PB-12A-L(WZS)")
(0)Model:PB-12A-L(WZS)
9-45VDC 1CH*(100-450mA) 12W Zigbee Constant Current Dimable LED Driver PB-12A-L(WZS)
- Input Voltage: 100~240VAC
- Output Voltage: 9-45VDC
- Alternating Current: 0.3A/0.15A
- Output Current: 100~450mA
- Output Power: Max.12W
- Max Output Voltage: 48VDC
- Dimming Range: 0~100％
- PWM Frequency: 4000Hz
Zigbee 3.0 or WiFi Constant Current LED Driver for smart lighting applications. Unlike traditional LED drivers, smart LED drivers have integrated smart features - wireless connectivity, allowing for remote control and management of the LED lights. This Smart LED Driver uses Zigbee 3.0 wireless communication technology and can be controlled by a smartphone or other compatible devices. It also...
.jpg "0/1-10V WiFi + RF + Push Dimmer L1(WT)")
(0)Model:L1(WT)
0/1-10V WiFi + RF + Push Dimmer L1(WT)
- Input Voltage: AC100-240V
- Output signal: 0/1-10V (20mA)
- Dimming level: 256 levels
- Dimming range: 0 -100%
- Warranty: 5 years
- IP rating: IP20
Features ● WiFi + RF + AC push 0/1-10V dimmer, 1 channel output. ● Output 1 channel 0/1-10V signal, connect with 0/1-10V dimmable driver. ● Tuya APP cloud control, support on/off, brightness adjust, delay turn on/off light, timer run, scene function. ● Voice control, support amazon ECHO and TmallGenie smart speaker. ● 0-10V or 1-10V output selectable by DIP switch. ● 256 levels 0-100%...
+R11-WiFi-RF-AC-Triac-Dimmer-Set.jpg "WiFi Tuya App & RF Push AC Triac Dimmer Set S1-B(WT)+R11")
(0)Model:S1-B(WT)+R11
WiFi Tuya App & RF Push AC Triac Dimmer Set S1-B(WT)+R11
- Input Voltage: AC100-240V
- Output Current: Max 1.5A
- Output Power: 150W-360W
- Dimming signal: Tuya+RF+Push Dim
Check this RF AC Triac Dimmer Set for your single-color dimmable LED lamps, traditional incandescent and halogen lights. You can use three methods to dim the lights, by your smartphone Tuya APP, through R11 handheld RF remote control, or your push switch. Features ● WiFi + RF + Push AC phase-cut dimmer, 1 channel output. ● To dim and switch single-color dimmable LED lamps,...
(0)Model:VD1-WT
VD1 (WT) WiFi Tuya And RF Push Button Dimmer Switch 5A
- Input Voltage: DC5-24V
- Output Current: Max 5A
- Output Power: 25W/60W/120W
- Control Mode: 3 buttons+RF+APP
- Dimming Curve: Logarithmic
- PWM Frequency: 2KHz
- Size: L73xW35xH14mm
- Warranty: 5 years
This VD1(WT) push button dimmer switch combines push button control with wireless remote control, you can dim the white LED strip lights in a variety of ways. The led dimmer body comes with three buttons, with functions 1) Turn on or off light; 2) Brightness +; 3) Brightness -. DC input and output interfaces for easy wiring. 10 light brightness levels, long press the brightness+/- button...
(0)Model:WT1+R11
12-36VDC 2CH*5A WiFi Tuya APP & RF Remote LED Dimmer Set WT1+R11
- Input voltage: 12-36VDC
- Output current: 2CH,5A/CH
- PWM Frequency: 2000Hz
- Output power: 2x(60-180W)
- Dimming signal: Tuya APP+RF+Push Dim
- Remote distance: 30m
This is a LED Dimmer Kit, includes a LED controller and a RF remote. WT1+R11 is a smart lighting control solution from Skydance that offers convenient and flexible control over single-color LED strip lights. The WT1 is a WiFi & RF LED Dimmer Controller that can be operated through the Tuya app, voice commands, or the R11 RF remote control, to provide constant voltage output for LED...
.jpg "3-24VDC 1CH*(350-700mA) 12W Zigbee Dimmable Constant Current LED Driver PB-12A-H(WZS)")
(0)Model:PB-12A-H(WZS)
3-24VDC 1CH*(350-700mA) 12W Zigbee Dimmable Constant Current LED Driver PB-12A-H(WZS)
- Input Voltage: 100~240VAC
- Output Voltage: 3-24VDC
- Alternating Current: 0.3A/0.15A
- Output Current: 350~700mA
- Output Power: Max.12W
- Max Output Voltage: 33VDC
- Dimming Range: 0~100％
- PWM Frequency: 4000Hz
This Intelligent Dimmable Constant Current LED Driver integrates with a Zigbee 3.0 or WiFi network, to dim LED lights through a smart device - a smartphone, a smart speaker, a remote control, or a smart home lighting center. The use of the Zigbee protocol ensures low-power, reliable wireless communication between the LED lights and the controlling device, offering a convenient and versatile...
 100-240VAC 01-10V Tuya WiFi & RF Tunable White Push LED Dimmer.jpg "L2(WT) 100-240VAC 0/1-10V Tuya WiFi & RF Tunable White Push LED Dimmer")
(0)Model:L2(WT)
L2(WT) 100-240VAC 0/1-10V Tuya WiFi & RF Tunable White Push LED Dimmer
- Input Voltage: AC100-240V
- Output signal: 2 x 0/1-10V
- Output current: -10-40°C
- RF: 20mA/CH; AC: Max 3A
- Input signal: Tuya APP+RF+Push Dim
- Dimming range: 0 -100%
- RF Control distance: 30m
- Warranty: 5 years
Product Feature ● WiFi + RF + AC push 0/1-10V dimmer, output 2 channel 0/1-10V signal. ● High voltage AC input, High voltage AC relay output. ● Dimming or dual color control selectable by DIP switch. ● For dual color control, the two channel output can be set as warm white and cool white respectively, or one for brightness adjust and the other for color temperature adjust. ● 0-10V or...
(0)Model:V5-L(WT)
V5-L(WT) WiFi & RF Tuya Push Dimming 5 in1 LED Controller Amazon ECHO Voice Control
- Input voltage: 12-48VDC
- Output voltage: 5*DC12-48V
- Input current: 30.5A
- Output type: Constant voltage
- Input signal: Tuya APP + RF 2.4GHz + Push Dim
- Control distance: 30m
- Dimming range: 0-100%
- Operation temperature: -30~+55"C
WiFi & RF 5 in1 LED Controller, Tuya APP cloud control /Voice control /5 Channels output /DC12-48V input /Four PWM frequency (500/2000/8000/16000Hz) /Push Dim. ● 5 in 1 function, used for control RGB, RGBW, RGB+CCT, color temperature, or single color LED strip. ● DC12-48V input, 5-channel constant voltage output. ● Tuya APP cloud control, support on/off, RGB color, color...
.jpg "100-240VAC 1.5A WiFi+RF+Push Switch SS-B(WT)")
(0)Model:SS-B(WT)
100-240VAC 1.5A WiFi+RF+Push Switch SS-B(WT)
- Output voltage:AC100-240V
- Output power:150-360W
- Remote Distance:30m
- Output current:1.5A
- OT:-30℃~+55℃
- IP rating:IP20
Features WIFI+RF+PUSH AC phase smart switch, without dimming function. To dim and switch single color LED lamps , traditional incandescent and halogen lights. Tuya APP cloud control, support on/off, delay turn on/off light,timer run function. Voice control, support amazon ECHO and TmallGenie smart sperker. Compatibility with RF 2.4G dimming remote control Each S1-B(WT) controller can also...
.jpg "1CH*1.5A WiFi-RF+Push AC Phase-cut Dimmer S1-B(WT)")
(0)Model:S1-B(WT)
1CH*1.5A WiFi-RF+Push AC Phase-cut Dimmer S1-B(WT)
- Input voltage:AC100-240V
- Output Voltage:AC100-240V
- Output Current:MAX 1.5A
- Output Power:150-360W
- Waterproof Rating:IP20
- Dimming Range:0-100%
Features WIFI+RF+PUSH AC phase-cut dimmer,1 channel output. To dim and switch single color dimmable LED lamps , traditional incandescent and halogen lights. Tuya APP cloud control, support on/off, color temperature and brightness adjust,delay turn on/off light,timer run, scene and music play function. Voice control, support amazon ECHO and TmallGenie smart sperker. 256 levels 0-100% dimming...
