LPD6803 IC Programmable LED Strips

How does LPD6803 addressable led strip light work?

LPD6803 is a 3-channel constant current driver IC with internal serial shift registers and cascaded driver circuits, using advanced high-voltage CMOS technology to achieve 256-level grayscale adjustment and output 16 million dynamic color chasing effects, which suitable for industrial lighting.

The DIN/DCLK port of LED strip inputs the serial data output by the SPI LED controller, and the data is shifted into the serial shift register on the upper edge of the clock. After dumping, it is converted to 3-port parallel output by pulse width modulation, serial shift register and the gray-scale counter can be controlled by different clock signals. LPD6803 drives the data and control signals internally and then outputs them to the next-level circuit, the data clock signal passes through the built-in phase-locked regeneration circuit and is strongly driven to provide the next-level chip to improve the cascade level. number, the maximum current of a single channel is 45mA,  supports DC12V input voltage.


LPD6803 DC12V 150LEDs RGB Series Flexible LED Strip Lights, Programmable Pixel Full Color Chasing, Indoor Use, 16.4ft Per Reel By Sale
Review stars(0)
Model:DCFLS-12V-LPD6803X150

LPD6803 DC12V 150LEDs RGB Series Flexible LED Strip Lights, Programmable Pixel Full Color Chasing, Indoor Use, 16.4ft Per Reel By Sale

  • IC Type: LPD6803 5050 RGB
  • Power: 36W//Roll
  • Voltage: DC12V
  • Brightness: 201lm/feet
  • FPCB Width: 10mm
  • FPCB Color:White/Black
  • Waterproof rating: Optional
  • LED Quantity: 30LEDs/m
Various Options In Stock
$27.98
Universal  LPD6803  dynamic color chasing, sequencing, changing, and also static color modes available on the Full-Color Controller and dream color Strip. individually addressable LEDs allow for sequencing modes. Silicone Encased waterproof flexible LED light strip with 150 LEDs high power 5050SMD(Surface Mounted Devices) RGB LEDs programmable for chasing patterns. 6803 IC chip...
LPD6803 DC12V Series Flexible LED Strip Lights, Programmable Pixel Full Color Chasing, Waterproof IP65, 150LEDs 16.4ft Per Reel By Sale
Review stars(0)
Model:DCFLS-IP65-LPD6803X150

LPD6803 DC12V Series Flexible LED Strip Lights, Programmable Pixel Full Color Chasing, Waterproof IP65, 150LEDs 16.4ft Per Reel By Sale

  • IC Type: LPD6803
  • Operating Voltage(v): 12
  • Wattage(W): 38
  • Programmable: Yes
  • Light Color: Full Color
  • Waterproof Rating: IP65
  • LED Pixels(QTY): 150
  • Lifespan(hours): 50,000+
Various Options In Stock
$31.98
Universal LPD6803 150xIP65 dynamic color chasing, sequencing, changing, and also static color modes available on the Full-Color Controller and dream color Strip. individually addressable LEDs allow for sequencing modes. Silicone Encased waterproof flexible LED light strip with 150 LEDs high power 5050SMD(Surface Mounted Devices) RGB LEDs programmable for chasing patterns. 6803 IC chip...
LPD6803 DC12V Series Flexible LED Strip Lights, Programmable Pixel Full Color Chasing, Outdoor Waterproof IP67, 150LEDs 16.4ft Per Reel By Sale
Review stars(0)
Model:DCFLS-IP67-LPD6803X150

LPD6803 DC12V Series Flexible LED Strip Lights, Programmable Pixel Full Color Chasing, Outdoor Waterproof IP67, 150LEDs 16.4ft Per Reel By Sale

  • IC Type: LPD6803
  • Operating Voltage(v): 12
  • Wattage(W): 38
  • Programmable: Yes
  • Light Color: Full Color
  • Waterproof Rating: IP67
  • LED Pixels(QTY): 150
  • Lifespan(hours): 50,000+
Various Options In Stock
$31.98
Universal LPD6803 150xIP67 dynamic color chasing, sequencing, changing, and also static color modes available on the Full-Color Controller and dream color Strip. individually addressable LEDs allow for sequencing modes. Silicone Encased waterproof flexible LED light strip with 150 LEDs high power 5050SMD(Surface Mounted Devices) RGB LEDs programmable for chasing patterns. 6803 IC chip...
LPD6803 DC12V 300LEDs RGB Series Flexible LED Strip Lights,Programmable Pixel Full Color Chasing, Indoor Use, 16.4ft Per Reel By Sale
Review stars(0)
Model:DCFLS-12V-LPD6803X300

LPD6803 DC12V 300LEDs RGB Series Flexible LED Strip Lights,Programmable Pixel Full Color Chasing, Indoor Use, 16.4ft Per Reel By Sale

  • IC Type: SK6812 5050 RGB
  • Power: 72W//Roll
  • Voltage: DC12V
  • Brightness:402lm/feet
  • FPCB Width: 10mm
  • FPCB Color:White/Black
  • Waterproof rating: Optional
  • LED Quantity: 60LEDs/m
Various Options In Stock
$57.98
Universal LPD6803  dynamic color chasing, sequencing, changing, and also static color modes available on the Full-Color Controller and dream color Strip. individually addressable LEDs allow for sequencing modes. Silicone Encased waterproof flexible LED light strip with 300 LEDs high power 5050SMD(Surface Mounted Devices) RGB LEDs programmable for chasing patterns. 6803 IC chip...
