Meanwell 24V outdoor power supplies for waterproof low voltage DC24V LED lighting projects. Available in Mean Well LPH 18W series, LPV 20W-150W series, XLG 50W-200W series, and HLG 480W-600W series. Please choose the right power for stable operation.
LED Power Supply Drives
Sponsors
Sponsors
MeanWell UL Outdoor Power Supplies
(0)Model:LPH-18-24
AC180~264V LPH-18-24 Input Mean Well High-efficacy Waterproof DC24V 18Watt UL-Listed LED Display Lighting Power Supply
- DC voltage: 24V
- Current Rating: 0.75A
- Current range: 0-0.75A
- Rated power: 18W
- Efficiency: 77%
- AC current: 0.3A / 230VAC
Note: The AC input voltage of this model is 180～264VAC Main features 180～264VAC AC input voltage Fully enclosed plastic shell, in line with IP67 protection standard With short circuit protection/overload protection/overvoltage protection/overheat protection International safety certification: TUV/CB/CE Constant pressure working mode Class II input, no shell grounding terminal Can...
(0)Model:LPV-20-24
LPV-20-24 20Watt AC90～264V Input Mean Well High-efficacy Waterproof DC24V UL-Listed LED Display Lighting Power Supply
- DC voltage:DC24V
- Rated current:0.84A
- Rated power:20.2W
- Current range:0-0.84A
- Efficiency:81%
Features: Constant voltage design Universal AC input/ Full range Withstand 300VAC surge input for 5 seconds Protections: Short circuit 1 Over load / Over voltage Cooling by free air convection Small and compact size Fully encapsulated with IP67 level (Note.7) Fully isolated plastic case Class I power unit, no FG Class 2 power unit Pass LPS Suitable for LED related fixture or appliance (such as...
(0)Model:LPV-35-24
LPV-35-24 36Watt AC90～264V Input Mean Well High-efficacy Waterproof DC24V UL-Listed LED Display Lighting Power Supply
- DC voltage:DC24V
- Rated current:1.5A
- Rated power:36W
- Current range:0-1.5A
- Efficiency:85%
MeanWell power supply is a professional power supplier with UL certification. LPV-35-24 is a constant voltage single output switching power supply with an input voltage range of 90～264VAC (international). Our customers are mainly concentrated in the United States (110V) and Europe (220V). ), so you can choose with confidence. The output voltage is DC24V, and the low voltage is characterized by...
(0)Model:LPV-60-24
LPV-60-24 60Watt AC90～264V Input Mean Well High-efficacy Waterproof DC24V UL-Listed LED Display Lighting Power Supply
- DC voltage:DC24V
- Rated current:2.5A
- Current range:0-2.5A
- Rated power:60W
- Efficiency:86%
- Input voltage:90～264VAC
MeanWell power supply is a professional power supplier with UL certification. LPV-60-24 is a constant voltage single output switching power supply with an input voltage range of 90～264VAC (international). Our customers are mainly concentrated in the United States (110V) and Europe (220V). ), so you can choose with confidence. The output voltage is DC24V, and the low voltage is characterized by...
(0)Model:LPV-100-24
LPV-100-24 100Watt AC90～264V Input Mean Well High-efficacy Waterproof DC24V UL-Listed LED Display Lighting Power Supply
- DC voltage:DC24V
- Rated current:4.2A
- Current range:0-4.2A
- Rated power:100.8W
- Efficiency:88%
- Input voltage:90～264VAC
The output voltage is DC24V, and the low voltage is characterized by safety and stability, energy-saving and environmental protection, and high efficiency. This power supply can withstand 300VAC surge input for 5 seconds, so you must pay attention when connecting high-voltage power. At the same time, this power supply has short-circuit/overload/overvoltage protection. IP67 waterproof can be...
(0)Model:LPV-150-24
LPV-150-24 150Watt AC110V Input Voltage Mean Well High-Efficacy Waterproof DC24V UL-Listed LED Display Lighting Power Supply
- DC voltage :DC24V
- Rated current: 6.3A
- Current range: 0-6.3A
- Rated power: 151.2W
- Efficiency: 89%
- Input voltage: 90～132VAC
LPVL-150-24 for 110V input, LPV-150-24 for 220V input. The main material used in the MEAN WELL LPV series is ultra-thin plastic, and the waterproof rating can reach IP67. The LP series LED driver has 300VAC surge input for 5 seconds, which can effectively avoid short circuit, load, and other safety problems. It is suitable for economical LED lighting and mobile sign applications. The input...
(0)Model:XLG-50-A
XLG-50-A 50Watt AC100-305V Input Voltage Mean Well High-Efficacy Waterproof UL-Listed LED Display Lighting Power Supply
- Rated Current:1A
- Rated Power:50W
- Output voltage:DC22-54V
- MAX Circuit Voltage:57V
- Frequency Range:47-63Hz
- Efficiency:90%
The difference between XLG-50-A and XLG-50-AB: XLG-50-A with single channel to power the controller or the led strip light XLG-50-AB: with dual channels to power the controller or the led strip light and with 3 in 1 dimming function(0~10Vdc,10V PWM signal and resistance) Note: Because the power supply is waterproof, we recommend that you choose the waterproof LED strip light. ...
(0)Model:XLG-50-AB
XLG-50-AB 50Watt AC100-305V Input Voltage Mean Well High-Efficacy Waterproof UL-Listed LED Display Lighting Power Supply
- Rated Current:1A
- Rated Power:50W
- Output voltage:DC22-54V
- MAX Circuit Voltage:57V
- Frequency Range:47-63Hz
- Efficiency:90%
The difference between XLG-50-A and XLG-50-AB: XLG-50-A with single channel to power the controller or the led strip light XLG-50-AB: with dual channels to power the controller or the led strip light and with 3 in 1 dimming function(0~10Vdc,10V PWM signal and resistance) Note: Because the power supply is waterproof, we recommend that you choose the waterproof LED strip light. ...
(0)Model:XLG-75-24-A
XLG-75-24-A 75Watt AC100-305V Input Voltage Mean Well High-Efficacy Waterproof DC24V UL-Listed LED Display Lighting Power Supply
- DC voltage:DC24V
- Rated current:3.1A
- Current range:0-3.1A
- Rated power:74.4W
- Efficiency:90%
- Input voltage:100～305VAC
Having received wide anticipation from the market after the launch of the XLG-25/50 series (25/50W), the XLG-75/100 series (75/100W) is now officially unveiled. With the constant power mode design and other advantages, it is believed the launch of the XLG-75/100 series not only meets customers’ demand for medium wattage but further facilitates the various LED light sources design and...
(0)Model:XLG-100-24-A
XLG-100-24-A 96Watt AC100-305V Input Voltage Mean Well High-Efficacy Waterproof DC24V UL-Listed LED Display Lighting Power Supply
- DC voltage:DC24V
- Rated current:4A
- Current range:0-4A
- Rated power:96W
- Efficiency:92%
- Input voltage:100～305VAC
Having received wide anticipation from the market after the launch of the XLG-25/50 series (25/50W), the XLG-75/100 series (75/100W) is now officially unveiled. With the constant power mode design and other advantages, it is believed the launch of the XLG-75/100 series not only meets customers’ demand for medium wattage but further facilitates the various LED light sources design and...
(0)Model:XLG-150-24-A
Meanwell XLG-150-24-A UL Listed IP67 24VDC 150W Power Supply
- DC voltage:DC24V
- Rated current:6.25A
- Current range:0-6.25A
- Rated power:150W
- Efficiency:93%
- Input voltage:100～305VAC
Meanwell XLG-150-24-A UL Listed IP67 24VDC 150W Power Supply Outdoor. XLG-150 series is a 150W LED AC/DC driver featuring the constant power mode. XLG-150 operates from 1 00~305VAC and offers models with different rated current ranging between 700mA and 12500mA.Thanks to the high efficiency up to 93%, with the fanless design, the entire series is able to operate for -40C ~+90°C case...
(0)Model:XLG-200-24-A
XLG-200-24-A 199.2Watt AC100-305V Input Voltage Mean Well Waterproof DC24V UL-Listed LED Power Supply
- DC voltage:DC24V
- Rated Current:8.3A
- Output Voltage:16.8V-24V
- Rated Power:199.2W
- Efficiency:94%
- Input Voltage:100～305VAC
XLG-200 series is a 200W LED AC/DC driver featuring the constant power mode. XLG-200 operates from 100~305VAC and offers models with different rated current ranging between 700mA and 16A. Thanks to the high efficiency of up to 94 %, with the fanless design, the entire series is able to operate tor - 40°C~+90°C case temperature under free air convection. The design of metal housing and...
(0)Model:HLG-480H-24B
HLG-480H-24B 480Watt AC90～305V Input Voltage Mean Well IP67 Waterproof DC24V UL-Listed LED Power Supply
- DC voltage:DC24V/36V/48V
- Rated Current:20A/13.33A/10A
- Rated Power:480W
- Efficiency:94%
- Input Voltage Range:90～305VAC
- Frequency Range:47-63Hz
- Waterproof Rating:IP67
HLG-480H series is a 480W AC/DC LED driver featuring the dual mode constant voltage and constantcurrentoutput. HLG-480H operates from 90-305VAC and offers models with different rated voltage ranging between 24V, 36V, 48V and 54V. Thanks to the high efficiency up to 95.5%, with the fanless design, the entire series is able tooperate for -40~ +90°C case temperature under free air convection....
(0)Model:HLG-600H-24B
HLG-600H-12B AC90-305V Input Voltage Mean Well Waterproof DC24V 600Watt UL-Listed LED Power Supply
- DC Voltage:DC24V/36V/48V
- Rated Current:25A/16.66A/12.5A
- Current Range:12.5-25A
- Rated Power:600W
- Load Regulation:±2%
- Efficiency:95%
- Input Voltage:90～305VAC
- Frequency Range:47-63Hz
HLG-600H series is a 600W AC/DC LED driver featuring the dual mode constant voltage and constant current output. HLG-600H operates from 90 ~ 305VAC and offers models with different rated voltage ranging between 12V, 36V, 48V and 54V. Thanks to the high efficiency up to 96%, with the fanless design, the entire series isable to operate for -40°C ~ +90°C case temperature under free air...
